Product Overview
1, triac output, zero voltage turn, zero current shutdown.
2, the input signal is compatible with TTL and COMS digital logic circuits.
3, the optical isolation between input circuit and output circuit.
4, light-emitting diodes indicate working status;
5, input - output isolation voltage between ≥2500V end.
6, high cost, widely used, highly reliable generic products.
Technical parameters:
Model classification TSR-10DA TSR-10DA-H
TSR-25DA TSR-25DA-H
TSR-40DA TSR-40DA-H
TSR-50DA TSR-50DA-H
TSR-60DA TSR-60DA-H
TSR-75DA TSR-75DA-H
Control DC control AC (DC-AC)
The load current is 10A, 25A, 40A, 50A, 60A, 75A
On-state leakage current ≤10mA
Buck-state ≤0.9VAC
Off-state time ≤10mS
Dielectric strength 2500VAC
Insulation resistance 1000MΩ / 500VDC
Ambient temperature -30 ℃ - + 75 ℃
Mounting Bolt
LED work instructions
